Low-voltage racked battery packs are an excellent choice for anyone looking for a reliable and long-lasting energy storage solution. The high-quality LFP battery cells used in each pack have a lifespan of at least 6000 cycles, which means they can be used over and over again for many years. In addition, these batteries have a discharging depth of 90%, which means they can be drained almost completely before needing to be recharged.
One of the best things about these battery packs is their durability and reliability. They are built to last and come with a 10-year warranty to prove it. This means you can rest assured that you are making a wise investment when you choose a low-voltage racked battery pack for your energy storage needs.
Each battery pack has a capacity of 5.12 kWh, which is plenty of energy to power your home or business for many hours. And if you need even more energy, you can stack up to 16 batteries directly in parallel to provide up to 80kWh of energy.
Overall, low-voltage racked battery packs are an excellent choice for anyone looking for a reliable, durable, and long-lasting energy storage solution. Whether you are powering your home, office, or industrial facility, these battery packs are sure to meet your needs and exceed your expectations. So why wait? Invest in a low-voltage racked battery pack today and start enjoying renewable energy at its best!
Low Voltage Racked Battery Specifications
Model | LFP 5000 |
---|---|
Total Energy* | 5 kWh |
Usable Energy (DC)* | 4.6 kWh |
Nominal Discharge/Charge Power | 3 kW |
Peak Power (discharge only) | 7 kW for 3 seconds |
Constant Current (discharge only) | 100 A |
Voltage Range | 43.2 Vdc to 56 Vdc |
Nominal Voltage | 51.2 Vdc |
Nominal Current | 50 A |
Maximum Charge Current | 50 A |
Maximum Discharge Current | 50 A |
Maximum Charge Voltage | 58.4 Vdc |
Weight in kg | 65 kg |
Dimensions in mm (L x W x H) | 453*433*177mm |
Safety Specifications | CE UN38.3 |
Maximum Recommended DOD | 90% DOD (maximum recommended) |
Operating Environment | rated indoors only |
Charging Temperature Range | 0℃ to 45℃ |
Discharging Temperature Range | -10℃ to 50℃ |
Storage Temperature Range | -20℃ to 50℃ |
Operating Humidity Range | 4% to 100% relative humidity (non-condensing) |
Pollution Degree | 3 |
Over Voltage Category | II |
Cooling Method | passive natural cooling |
Case Material | Metal |
IP rating | IP 20 |
Protective Class | I |
Max. Number of Batteries in Parallel or Series | 16 |
Warranty | 10 years |
Life Span Expectations | more than 15 years |
Communication | CAN Bus RS-485 |
Protection Mode | triple hardware protection |
Battery Protection | over-current / over-voltage / short circuit / under-voltage |
Hazardous Material Classification | 9 |
